WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking

1 Takım
MOQ
Negotiable（USD,EUR）
fiyat
WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Puanlar ve İncelemeler Fiyat talebi
Özellikleri
Teknik Özellikler
OEM / DOM: 55KW
Üretim tipi: Ortak ekstrüzyon
Hammadde uyumluluğu: Ağaç lifi, plastik tozu, katkı maddeleri
Genişlik: 200,240,300,400 mm
Vida Tasarımı: Çift vidalı
Çıkış kapasitesi: Saatte 1000-1500 kg
Ürün genişlik aralığı: 100-200mm
Liman: Dolap
Üretim hattı türü: Otomatik sürekli üretim hattı
Çıkış Kapasitesi: 250kg/saat
Vurgulamak:

WPC decking machine with wear resistance

,

outdoor WPC decking line

,

compressive strength WPC decking machine
Temel bilgiler
Menşe yeri: Zhangjiagang
Marka adı: LB
Sertifika: CE,ISO
Model numarası: LB-300W
Ödeme & teslimat koşulları
Ambalaj bilgileri: STANDART PAKET
Teslim süresi: 45 İŞ GÜNÜ
Ödeme koşulları: L/C,T/T
Yetenek temini: Ayda 15 takım
Ürün Açıklaması
WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking
Conical Twin Screw Extruder

Designed for PVC profile applications with flexibility in material choices, high performance, and long durability.

  • High flexibility in raw material combinations
  • Gentle and homogeneous plastification
  • Barrel with air cooling system
  • AC motors for low energy consumption
  • Control panel with color touch screen
Energy Saving System (LESS)

Lima Energy Saving System provides significant vacuum energy savings.

  • Vacuum energy savings up to 80%
  • Vacuum pumps driven by individual frequency inverters
  • Low noise level operation
  • Closed circuit water system
Crawler Track Haul-off Units

Flexible solutions with independent tracks and continuous speed adjustment.

  • Flexibility in pad dimensions
  • Two independent tracks with gearboxes
  • Speed adjustment by inverter
Complete Extrusion Line Components
Conical Twin Screw Extruder: Special screw and barrel design for perfect mixing and homogeneous output with motors for minimal electricity consumption.
Mould: Ideal viscosity design with polished contact surfaces to minimize friction losses.
Calibration Table: Stainless steel construction to prevent corrosion with customized design for profile characteristics.
Crawler Track Haul-off: Inverter-controlled speed adjustment synchronized with material output rate.
Saw Cutter: High-efficiency cutting with integrated dust collection system.
Tip-off Unit: Pneumatic cylinder operation.
Production Specifications
MODEL PROFILE SIZE (mm) EXTRUDER MODEL MOTOR POWER (kw)
LB-108 108 SJZ51/105 18.5 AC
LB-180 180 SJZ55/110 22 AC
LB-300 300 SJZ65/132 37 AC
LB-600 600 SJZ80/156 55 AC
LB-800 800 SJZ80/156 55 AC
LB-1240 1240 SJZ92/188 110 D

WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking 0

WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking 1

WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking 2

WPC Decking Line with Wear Resistance and Compressive Strength Suitable for Outdoor Decking 3
