HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine

1 Takım
MOQ
USD,EUR
fiyat
HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Puanlar ve İncelemeler Fiyat talebi
Özellikleri
Teknik Özellikler
Vurgulamak:

HDPE plastic biofilter media machine

,

K1 K3 K5 Mbbr biofilter extruder

,

biofilter media extrusion line
Temel bilgiler
Menşe yeri: Zhangjiagang
Marka adı: LB
Sertifika: CE,ISO
Model numarası: LB-65/33
Ödeme & teslimat koşulları
Ambalaj bilgileri: STANDART PAKET
Teslim süresi: 45 Woking Günü
Ödeme koşulları: L/C,T/T
Yetenek temini: Ayda 15 Takım
Ürün Açıklaması
Complete production system for manufacturing K1, K3, K5 MBBR biofilter media used in water treatment applications.
Product Overview
This specialized extrusion line is designed for producing MBBR (Moving Bed Biofilm Reactor) profile media used in wastewater treatment systems. The equipment creates high-density polyethylene biofilter media with optimal surface area for microbial growth.
Processing Technology
The production process follows this sequence: HDPE material + additives → mixing material feeder → twin screw extruder → specialized mould and calibrator → vacuum forming table → haul-off machine → cutting machine → discharge rack.
Key Features
  • Conical twin screw extruder suitable for HDPE materials
  • Integrated degassing system ensures excellent material plasticization
  • High-speed mould technology for increased productivity
  • Precision calibration for consistent media dimensions
  • Automated cutting and discharge systems
Technical Specifications
Model LB180 LB240 LB300 LB600
Max Product Width (mm) 180 240 300 600
Screw Model SJ55/110 SJ65/132 SJ65/132 SJ80/156
Motor Power 22KW 37KW 37KW 55KW
Cooling Water (m³/h) 5 7 7 10
Compressor (m³/h) 0.2 0.3 0.3 0.4
Total Length (m) 18 22 22 25
Production Line Images
HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine 0 HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine 1 HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine 2 HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine 3 HDPE Plastic Biofilter Media Extrusion Line/K1 K3 K5 Mbbr Biofilter Media Making Machine 4
